1. Visit our Network Status page to see if any known issues in your area are affecting your internet connection.
  2. Run a speed test. If your result is lower than 3Mbps please call our Support Team on 13 22 58.
  3. Multiple devices competing for bandwidth on your home network (e.g. downloading a movie or major game patch while watching/recording a Fetch channel) may cause temporary bandwidth issues.
  4. Reduce the number of high-bandwidth activities running at the same time to allow more bandwidth for your Fetch service.
    Note: If the issue is temporary due to local congestion, you can prevent repeated display of the "Bandwidth Low" message by pressing the green button on your Fetch remote.
  5. Open the Fetch menu and select the Gear icon.
  6. Select User > Streaming. You may need to enter the parental PIN to continue (the default PIN is 0000).
  7. Select a suitable bandwidth setting:

    - 3 channels (6 Mbps) - Limits Fetch to 3 streams (watch/record up to 3 channels at a time). Try this setting first.
    - 2 channels (4 Mbps): Limits Fetch to 2 streams (watch/record up to 2 channels at a time). Choose this setting if channels don't play smoothly when "3 channels (6 Mbps)" is selected.
    - 1 channel (2 Mbps): Limits Fetch to 1 stream (watch/record one linear channel at a time). Choose this setting as a last resort.

    Fetch bandwidth settings example
  8. Changes will save automatically. Exit the Fetch menu to finish.
  9. Call us on 1300 701 006 for further assistance.

This article will show you how to how to run a ping test and traceroute using PingPlotter 5 Free, a third-party application available on Windows, macOS and iOS. If you have an Android OS device, you'll need to run this test using a desktop computer with Windows or macOS.

Note: These simple tests do not require Standard or Professional subscriptions; using the Free version will suffice.

Select one of the links below to jump to a query:



Using PingPlotter on Windows

  1. Visit http://pingplotter.com/download to download and install the PingPlotter application.
  2. After running through the installation, launch the application. Hit the + (plus) icon at the top of the page to open a New Trace tab.
    Windows PingPlotter ping test 1
  3. Type iinet.net.au or another address you wish to ping/traceroute into the address bar and hit the Start button to begin the test.
    Windows PingPlotter ping test 2
  4. Allow the test to run for at least a minute. Once the test results appear relatively stable, hit the Pause button.
    Windows PingPlotter ping test 3
  5. Use the Print Screen (PrntScr) key on your keyboard to take a screenshot of the test results. You can use CTRL+V to paste this screenshot directly into an email to send to support@iinet.net.au.

    Please be sure to include your username or account number plus any reference number you've been provided regarding your issue so we can make a note of the test results on your account and provide further assistance.



Using PingPlotter on macOS

  1. Visit http://pingplotter.com/download to download and install the PingPlotter application.
  2. After running through the installation, launch the application.
  3. Type iinet.net.au or another address you wish to ping/traceroute into the address bar at the top of the page, then hit the Start button to begin the test.
    Mac PingPlotter ping test 1
  4. Allow the test to run for at least a minute. Once the test results appear relatively stable, hit the Pause button.
    Mac PingPlotter ping test 2
  5. Use the Command+Shift+3 keys on your keyboard to take a screenshot of the test results. You can use Command+V to paste this screenshot directly into an email to send to support@iinet.net.au.

    Please be sure to include your username or account number plus any reference number you've been provided regarding your issue so we can make a note of the test results on your account and provide further assistance.



Using PingPlotter on iOS (iPhone/iPad)

  1. Open the App Store and run a search for 'PingPlotter" to find, download and install the PingPlotter app.
    PingPlotter on App Store
  2. Once the app has installed, open it and type iinet.net.au or another address you wish to ping/traceroute into the address bar at the top of the screen, then hit the Start button to begin the test.
    pingplotter_ios2ii
  3. Allow the test to run for at least a minute. Once the test results appear relatively stable, hit the Pause button.
    iPhone PingPlotter ping test 1
  4. Hit the Share icon and select Screenshot
    iPhone PingPlotter ping test 2
  5. Select to share via Mail and address the email to support@iinet.net.au.

    Please be sure to include your username or account number plus any reference number you've been provided regarding your issue so we can make a note of the test results on your account and provide further assistance.

Without bandwidth control, your modem/router may attempt to upload faster than the speed of your NBN® plan, which will result in your connection dropping out as NBN will start discarding information sent across the connection.

All modems supplied by iiNet take care of this setting automatically to ensure you have the fastest and most stable connection possible.

Note: If you have any trouble following this guide, please run a Google search or visit your modem/router manufacturer's website for support information.



  1. On a device that's connected to your modem, open your web browser and go to your modem's default gateway (this is the page where you can log in and change the modem settings). Common addresses are http://192.168.1.1, http://192.168.0.1 and http://192.168.1.254.

    If these don't work for you, check your modem manufacturer's website for support information. Alternatively, if you have a desktop PC or Mac you can follow the advice in this article to find the gateway address.
  2. You'll see a login page. If there's a username field, the default username will almost always be admin. The default password is typically admin or password.

    If you can't log in with these settings, check the modem's barcode sticker for the default login settings. If the modem is secondhand or you've used it previously, it may already have custom login details set. As a last resort, you can factory reset the modem to return it to the default settings.
  3. The setting you need to find is most likely in an Advanced section. If you see any option for advanced settings or to switch to an advanced view, select it.
  4. Locate the bandwidth control setting. This is commonly labelled QoS or Bandwidth/Traffic control.
  5. Ensure that upstream bandwidth/QoS is enabled and set the bandwidth maximum according to your NBN plan as listed below.

    - If you have an NBN12 plan, enter a maximum of 950kbps
    - If you have an NBN25 plan, enter a maximum of 4950kbps
    - If you have an NBN50 plan, enter a maximum of 19500kbps
    - If you have an NBN100 plan, enter a maximum of 19500kbps*
    - If you have an NBN250 plan, enter a maximum of 24500kbps
    - If you have an NBN Ultrafast plan, enter a maximum of 49500kbps

    *Note:
    Business NBN100 plans and some legacy residential NBN100 plans may require a maximum of 39500kbps instead.

  6. Save your changes to finish. An example for a Netgear modem is shown below.
    Netgear bandwidth control example



This article covers features for all current iiNet VoIP services such as NBN® Phone, VDSL2 Phone and FTTB Phone.

These services do not have a voice mail feature.

If you've never logged into Toolbox before, please see An Introduction to Toolbox.

Cost information

Standard features are included with your VoIP service, but please note that standard call costs apply when any call forwarding features forward a call to a new destination. All call forwarding features are disabled by default.

Select one of the links below to jump to a query:

CLID Blocking (Silent Number)

CLID Blocking (Calling Line ID Blocking), which may also be known as Silent Number to former landline users, blocks your phone number from being displayed to the person you’re calling. It is disabled by default.

  1. Log in to Toolbox and select the VoIP service under Select service to manage
    Toolbox service selection
  2. Select Settings.
  3. CLID Blocking can be enabled by setting its toggle switch to ON. Changes are saved automatically.
    CLID Blocking
  4. While CLID Blocking is enabled, you can disable it for a single call by dialing *65 before the number you’re calling.

Call Barring

Call Barring blocks specific types of calls from being made using your phone service. It is disabled by default, but the following barring types are available:

  • Bar outgoing long distance (STD) calls
  • Bar outgoing calls to Australian mobile phones
  • Bar outgoing International calls
  1. Log in to Toolbox and select the VoIP service under Select service to manage
    Toolbox service selection
  2. Select Settings.
  3. Each type of Call Barring can be enabled by setting its toggle switch to ON. Changes are saved automatically.
    Call Barring

Call Forwarding/Diverting

Call forwarding allows you to divert calls from your phone number to different number in the following circumstances:

  • Always
  • When your number is busy
  • When calls to your number aren't answered

Standard call costs apply when any call forwarding features forward a call to a new destination. All call forwarding features are disabled by default.

  1. Log in to Toolbox and select the VoIP service under Select service to manage
    Toolbox service selection
  2. Select Settings.
  3. Each type of Call Forwarding can be enabled by setting its toggle switch to ON, and entering the destination phone number in the text box.
  4. Select Update to save any changes.
    Call Forwarding

Call Waiting

If someone calls your phone number while you’re on a call, Call Waiting allows you to put someone on hold. Call Waiting is enabled by default and currently, it cannot be disabled in Toolbox. If you’d like to disable Call Waiting, please call us on 13 22 58 and we’ll be happy to help.

  1. While on a call, you’ll hear a tone when there is another call waiting. To switch back and forth between the two calls, press the CALL button on your handset and then dial 2.
  2. To hang up on the person you’re currently speaking to and switch to the other caller, press the CALL button on your handset and then dial 1.

Call Return

Please note that dialling *69 is not supported for these services. However, handsets with a built-in call return function will work. Standard call costs apply.

Invoice alignments make sure you're billed the correct rate for the exact days you had a particular plan or service.

When you first order iiNet services, you make a prepayment for your monthly plan fees.

This article will explain invoice alignments and prepayments in more detail.



When your first iiNet service is ordered, your "anniversary date" is set roughly 14 calendar days later. This is the date your iiNet bills are typically due each month. As a rule, billing anniversary dates don't get set for the 29th, 30th or 31st days of a month - only days 1 to 28 are used.

The billing period for your iiNet services is also based on your anniversary date (e.g. Billed period: 04 JAN 2017 - 04 FEB 2017). If you change plans, billing is aligned to the same billing period.



As per the Billing Policy in our Customer Relationship Agreement, iiNet services are billed in the following ways:

  • Recurring or fixed charges such as monthly plan fees are billed in advance. One month's pre-payment for services is taken immediately after your order is placed, but this prepayment stays on your iiNet account until your services are active and ready to be billed.
  • Variable charges such as phone calls are billed in arrears, which means they are paid after the charges have accrued (after all, we can't know which phone calls you've made until after you've made them!).

When you change plans, you'll receive a credit on your iiNet account for any unused plan fees that you paid in advance. You will then be charged in advance at the rate for your new plan.



The example below shows the initial setup charges for an internet service that was just ordered, as well as the one month's prepayment that's taken immediately whenever an order is placed.

  • A) Details about the payment that was taken from your nominated bank account or credit card
  • B) One month's pre-payment for your ordered plan
  • C) One-off setup charges such as broadband activation, modem purchases and hardware delivery
Invoice example 1

Example: The second invoice after placing an order (alignments)

The example below shows the charges for an internet service that has now been activated and billing has commenced. Credit from the one month's prepayment is used to balance one month's worth of charges now that the service is active.

  • A) Credit from pre-payment will be used to balance some of the charges on this invoice, so you're not paying for any days before your broadband service was activated
  • B) One Full Monthly Charge for the next billing period (one billing period in advance)
  • C) One Full Monthly Charge for the current billing period
  • D) In this example, the broadband service was active for 11 days before the beginning of the current billing period. A pro-rated charge covers the cost of these days
Invoice example 2

Please note: If you're trying to follow along with a calculator, it's worth noting that our billing system calculates fees right down to the second. It's unlikely that a service would be activated at exactly 12AM, so while a plan may cost $1.97 for each full day of the year, less than that would be charged for the day a service was activated.



This can happen when you change plans, or activate a new service partway through your billing period.

If you've been billed for a part month charge for your plan, then you'll receive a proportionate part of your plan's monthly value for data or calls, etc.

For example, if you've been billed for 10 days worth of your new broadband service with an included Netphone, you'll receive 10 days worth of its included monthly data and call value.

This is known as "pro-rating", and it means that you'll pay the correct rate and receive the correct value for the exact days you had each plan. Once your next billing period begins, you'll receive the full monthly value at the full monthly price.

Pro-rating does not affect unlimited or all-inclusive allowances, such as our Liimitless broadband data plans. After all, you can't divide infinity!



When you change plans or cancel a service, any amount you've paid in advance for that service is credited back to your account.

  • If you've changed plans, you'll then be billed in advance at the rate for your new plan. Any remaining credit will be used to balance charges on your next invoice.
  • If you're cancelling one service but you still have others, the credit will be used to balance charges on your next invoice.
  • If you're closing your account, any remaining credit after your final invoice can be refunded back to your nominated bank account or credit card.

This article will help iiNet customers who have services across two billing systems understand the differences between their two iiNet accounts and how they can manage their services. We call these customers "dual account" customers.



iiNet is currently in the process of implementing a new billing system behind the scenes. It's a gradual process to release our existing broadband products on this billing system. Currently, our new billing system is used for:

  • Mobile SIM plans
  • NBN services
  • Home Wireless Broadband services
  • ULTRA Broadband services

In some cases, existing customers may also have iiNet services which aren't yet available in the new billing system. That means that they'll have two accounts which need to continue indefinitely until we're able to get all of their services in the new billing system. We call this situation a "dual account".



Nope. Simply use the standard contact information available on our Contact Us page and follow the prompts to get through to the department you need.



Yes. Each billing system will issue its own invoice for the services on each account. Don't worry, though - you won't be billed twice for the same service as one service can only exist in one billing system. You'll receive your invoices via email as usual and payment will be automatically debited from your nominated bank account or credit card in time for the due date.

These invoices look different. At a glance, you can see that it's pretty easy to tell which is which. You can also take a look at the services which are listed on your invoice to confirm which is which.

Invoice from existing billing system
Invoice from new billing system
Old invoice example
New invoice example
Learn more about billing periods for this invoice
Learn more about billing periods for this invoice

How do I manage my services online in Toolbox?

Just like dual account customers have two different invoices, there are two different versions of Toolbox to use to manage your account online; one for your services in our existing billing system, and one for your services in our new billing system.

You can log into either Toolbox from the same place, our main login page at https://toolbox3.iinet.net.au/. The trick to getting one Toolbox or the other is the credentials you use to log in.

Toolbox for existing billing system Toolbox for new billing system
Log in at https://toolbox3.iinet.net.au/ with the username and password for the iiNet mailbox associated with your iiNet Mobile service (this may be your username with "_mobile" at the end), or old iiNet broadband service.
Log in at https://toolbox3.iinet.net.au/ with the username and password associated with your new iiNet service.
Old Toolbox example
New Toolbox example
Learn more about what you can do in this Toolbox
Learn more about what you can do in this Toolbox

if you've forgotten your password for either Toolbox, please use our password recovery tool.



From time to time, you may need to check out a guide on iiHelp to read up on how to do something related to your iiNet account or services. The majority of articles, such as those for troubleshooting services, can be used by any iiNet customer, regardless of which billing system their services are in. However, some articles, particularly those about billing and Toolbox, have different information that's relevant to either our existing billing system, or our new billing system.

So, how do you get the information you're looking for? It's pretty simple. Whenever an iiHelp article has equivalent articles for each billing system, you'll see a banner like the example below. You can use this banner to make a selection so you'll be shown the right stuff.

which Toolbox

Simply click the link and choose what your invoice or Toolbox looks like and you'll be taken to the relevant advice in the article.

which Toolbox

If you need to change your decision, simply scroll back to the top of the article and choose again.

iihelpequiv4

This article will explain the status lights found on the Cable Gateway Pro (EPC3940L) supplied for iiNet Cable services, which may be useful when troubleshooting.

Important light states to note

  • If the US and DS lights are BLINKING but the Online light is OFF, the Cable service may not yet be activated on our end. This typically occurs within one business day of your Cable service connection appointment. If you have any concerns, please call us on 13 22 58 and we'll be happy to help.
  • If the US and DS lights are BLINKING and the Online light is ON, the modem is updating its firmware. No action is needed - simply wait for the update to complete.



Status lights

Light State Meaning
1) Power Off Modem has no power.
Green Modem has power.
2) DS Off Not connected to the Cable network or modem has no power. Troubleshoot no connection.
Green Modem is online. Flashes during initial search for a downstream channel.
3) US Off Not connected to the Cable network or modem has no power. Troubleshoot no connection.
Green Modem is online. Flashes during initial search for an upstream channel.
4) Online Off Modem is not registered/online on the Cable network or modem has no power. Troubleshoot no connection.
Green Modem is registered to the Cable network and fully operational.
5) Ethernet 1-4 Off Nothing connected to Ethernet port or modem has no power. If something is plugged in, try a different Ethernet cable.
Green Ethernet connection to corresponding Ethernet port. Flashes during Ethernet connection activity.
6) Wireless button N/A Not a light Press to turn both 2.4GHz and 5GHz WiFi ability on/off.
7/8) 2.4G/5G Wireless Off 2.4GHz or 5GHz WiFi disabled or modem has no power.
Green 2.4Ghz or 5GHz WiFi enabled. Flashes during WiFi network activity.
9) WPS Button N/A Not a light Press to enable WPS search mode.
10/11) TEL1/TEL2 Off Netphone (VoIP) disabled or modem has no power.
Green Netphone (VoIP) enabled. Flashes during calls.





Cable Gateway Pro (EPC3940L)

This feature is available for NBN™ FTTB/FTTN/FTTC/FTTP & HFC only. If you have a different type of broadband, you'll need to contact us to reschedule.

If you've never logged into Toolbox before, please see An Introduction to Toolbox.



  1. Log in to Toolbox and select My Products from the navigation bar, and then select Broadband. If you're on a mobile device and you don't see this option, click the grey square with three lines to show the navigation menu.
  2. If you have more than one broadband service, select the right username from the Product drop-down menu.
  3. Select Manage NBN appointment from the Actions menu. If you're on a mobile device and you don't see the Actions menu, click the grey bar labelled Broadband actions to show it.
  4. Select Reschedule. Note that this option will only be displayed for appointments with the "Reserved" status.
    Toolbox NBN reschedule 1
  5. Fill out the form to select your desired date and time slot.

    IMPORTANT: As per the on-screen warning, all requests for a weekend or public holiday appointment will be rejected. Please take care not to do this as it may cause delays in your order.

    Toolbox NBN reschedule 2
  6. Click Submit to submit your request to reschedule.
  7. Once your appointment has been successfully rescheduled, you'll receive an email and/or SMS from us to confirm. In the event that your request is rejected (i.e. a weekend or public holiday was selected) we'll contact you to arrange an available appointment.

The article will explain the status lights found on the Network Termination Units (NTU) used for iiNet Fibre to the Building (FTTB) services.

Select your NTU model

LEA Networks NTU (LED zoom in)

LEA Networks NTU

Power/DIAG NTU

Power/DIAG NTU

LEA Networks NTU Stats lights

LEA Networks NTU
Light State Meaning
POWER Off No power supply.
Green NTU has power.
OUT Off The NTU does not detect the FTTB equipment in the basement MDF.
Green NTU is operating normally.
Flashing green Line issue detected. Check the phone cable is securely plugged into the LINE+POWER socket and the phone socket on the wall. Try an alternative phone wall socket if available. Please call us on 13 22 58 if the issue persists.
WARNING Off NTU is operating normally.
Flashing green Overload detected. Unplug the power cord from the NTU and then plug it back in. Please call us on 13 22 58 if the issue persists.



Power/DIAG NTU Status lights

iiNet FTTB NTU
Light State Meaning
POWER Off No power supply. Check the status of the DIAG light below.
Green NTU has power.
Flashing NTU may be malfunctioning. Please call us on 13 22 58 for assistance.
DIAG Off Provided POWER light is on and not flashing, the NTU is functioning as expected.
Red (and the POWER light is on) The line is in open circuit. Check the phone cable is connected securely to the NTU's UPLINK port and the phone socket on the wall, and try an alternate phone cable. If the issue persists, please call us on 13 22 58 for assistance.
Red (and the POWER light is off) The line is in short circuit. Try an alternative phone cable to connect the NTU's UPLINK port to the phone socket on the wall. If the issue persists, please call us on 13 22 58 for assistance.

The article will explain the status lights found on the NBN® Connection Device (NCD) used for NBN Fibre to the Curb (FTTC) services, which may be useful for  troubleshooting.

Status lights

The status lights may be covered by a small sliding panel on the face of your NBN Connection Device.

NBN FTTC NCD lights
Light State Meaning
LAN Off NCD has no power or is not connected to a modem/router.
Blue Successful connection between NCD and modem/router. Flashing indicates local network activity.
Amber Successful connection between NCD and modem/router. Flashing indicates local network activity.
DSL Off NCD has no power or is not communicating with the NBN access network.
Blue NCD is successfully communicating with the NBN access network.
Connection Off NCD has no power.
Blue Successful reverse power to NBN equipment outside the premises.
Red Issue with reverse power. Please call us on 13 22 58 for assistance.
Power Off NCD has no power.
Blue NCD has power.
